Get Hot sale 3w 5w 7w 10w cob led downlight dimmable recessed lamp home led epistar spot led kitchen 110v 220v only US $2.28 - 10.56 just for today
click button to claim coupon
Qualtity COB LED Downlight
LEDSONLINE
Parameter
Name: COB LED Downlight
Brand: LEDSONLINE
Watts: 3W / 5W
Voltage: AC110V 220V
Beam Angle: 30°
Color: Pure White 7000K
Natural White 4500K
Warm White 3000K
Size: D85*H 42mm
If you have any question, please leave us message before you place a order, thanks!
Hole Size: 68-75mm
Body Color: White
Diameter: 85mm / 3.35in
Cut Hole: 68-75mm / 2.68-2.95in
Height:42mm / 1.65n
Name: COB LED Downlight
Brand: LEDSONLINE
Watts: 10W
Voltage: AC110V 220V
Beam Angle: 30°
Color: Pure White 7000K
Natural White 4500K
Warm White 3000K
Size: D110*H 65mm
Hole Size: 90-98mm
Body Color: White
Diameter: 110mm / 4.33in
Height:65mm / 2.6in
Cut Hole: 90-98mm / 6.54-3.85in
PRODUCT SHOWCASE
COB 3W 5W 10W LED Downlight
Colors Option
Adjustable
The led lamp can be adjustable
30 degree each side.
Pure White 7000K
Natural White 4000K
Warm White 3000K
Bathroom
Bedroom
Kitchen
Details
COB Light Source
Newest design
Epistar Chip
More uniform and solft light
LED Driver
Independent / Intelligent IC /constant current
Isolated
1. Power factor(PF) >85%.
2. Short circuit Overvoltage protection
good fro led lamp.
3. Good design. Stable.
4. Supports more lamp connections (series /
parallel connection).
5. More safety for led lamp and your home.
Back Side
Wheel design, better heat dissipation
Tips: Each part of the lamp body can be disassembled and repaired.
Weight Measurement
3W / 5W
10W
LED Light + Driver
Net Weight: 111.3g
Add natural inner white box
Weight: 140g
Standard Package
10pcs/carton
Weight: 1700g
Strong
3W/5W as reference
LED Downlight Installation Instruction
Notice:
1.Apply that these must be installing by an authorized installer.
2.Please check the product if it was broken during the transport
before using.
3.Indoor using only. Waterproof grade is IP44.
4.The distance between the products and the inflammable material
should be 0.2m at least.To pay attention to distinguish the low
voltage and the high-voltage,separately go line.
5.The wire behind the light fitting can be fixed by cable clip.Ensure
fixed tightly.
6.Ensure the wire of power supply is long enough,don't have
tension or tangential force.Avoid big tension,and don't tie a knot.
And don't mix up the output wire.
7.After installing,connect the input wire of led recessed down light
with output wire of power supply.
8.Connect the input wire of power supply with electric supply,
generally speaking,the brown line is live line,and the blue line
is null line.
9.Don't use the professional led recessed down light driver for
other lighting.
Installation setps:
1. Off driver to open the
package
2. Measure the hole size
of downlight
3. Connect driver to your
main power
4. Make hole in the
Ceiling
5. Put the driver at the back
of ceiling
6. Make sure the driver is
firmly connected to led
downlight.
7. End
Attention:
1. Please make sure the hole size
match with led downlight housing.
2. Please connect the led downlight
to correct driver.
3. Please power off the electric
when install the downlight
ATTENTION
TO SAFETY
DANGER!
ELECTRIC SHOCK
Certificate
Good Color Rendering Index
LEDSONLINE's LED Light
CRI >85
Other cheap lights
CRI <85
Buyer's Sharing Pictures
1. Express Remote Cost: If your address was remote when send by DHL,FEDEX,UPS,TNT, then you should add remote cost $35 or provide
other normal address.
2. Customs Clearance: Please keep your phone working during transit until you get parcel. Assist clearance is the buyer responsibility if your
local Customs required . Any files request, please feel free to contact customer service. If the goods are detained, returned or destroyed by
buyer. There no compensation. If the issue is by the products, full refund will be given. Please pay attention to avoid unnecessary losses.
3. Custom Duty: Since the customs duties rules and calculation methods of each country are different, and are not controllable by sellers, so
our prices do not include customs duties and any additional charges.But we'll declare the lower value than original on the invoice/bill to help
avoid custom duty. If the parcel get strict inspected by custom. You still need to pay tax to clear custom. We won't bear the customs taxes.
If you have special requests,please contact us. So you may need pay the custom duty when you receive the parcel,pls understand.
Buyer Notice (Important)
SHIPPING
PAYMENT
1. We accept Alipay/West Union/PayPal/TT. All major credit cards are accepted through secure payment processor escrow .
2. If you can't checkout immediately after auction close, please wait for a few minutes and retry payments must be completed within 3 days.
3. If you want adjust total price, Please don't make payment immediately after you confirm "place order". Then our customer service will adjust
it and let you know.
WARRANTY
1. Over Guarantees delivery time still no delivery, Please contact us first. We'll processing according shipping details.
2. If no quality problem, we won't accept return.
3. 7 days: worranty-free money back Guaranty due to the product's quality problem. Except the improper operation of the buyer.
4. 7-90 days: If the product failed due to quality fault, LEDSONLINE will offer refund or free resend. Please send picture or video.
5. 90day -12 month: If your products faild to work due to quality issue after you received 90 days. Please contact customer service
first. We can resend new one to replace or repair after we confirm the product's problem. But the buyer should pay for the shipping fee.
ABOUT US
LEDSONLINE is a professional LED products manufacturer in China,Our goal is to provide our customer and partners such as Aliexpress
sellers, store owners, wholesalers high quality goods at a competitive price; And our cost savings are passed along to our customers as your
profit. Abiding by the principle of "Super quality, satisfactory service", we are striving hard to be your good business partner. We are convinced
that with joint efforts, the business between us will grow to benefit both of us. We can assure you of the high quality based on the most
preferential price .
Our Missions:
1. To export high quality goods from the orient at a competitive price to you.
2. To work with our customers to build up his business.
3. To maximize our international buyer's profitability and competitivenes
Hope you will give us positive 5 star feedback. Any question, please feel free to contact us. We'll try my best to help you solve it .
